Juice
Pressed juice moves to finishing, concentration, treatment and filling. Measure it at defined points and state whether the figure is before or after finishing.
PROCESS FLOW
The front end is shared.
The finishing route is chosen.
A process flow is useful when it shows the material streams and the decisions, not just a row of machine icons. Start with whole fruit, then follow the juice, pomace and cleaning streams.
MATERIAL STREAMSREAD LEFT TO RIGHT
JuiceProduct stream
PomaceSeparate outlet
CleaningIndependent state
The diagram is a process boundary. Equipment dimensions, connections and controls come from the approved project documents.
SHARED FRONT END
Four duties before
the product splits.
These stages are common to the whole-fruit routes on this site. The exact equipment inside each duty still depends on the fruit and the project.
THE PRODUCT DECISION
What happens to
the pressed juice?
Clarity and concentration are separate choices. Select both to see the route and the equipment that changes.
CLEARNFC
Clear NFC apple juice
The clarity target introduces a finishing branch. NFC describes the absence of concentration, not whether suspended material is retained.
View route →CLOUDYNFC
Cloudy NFC apple juice
The process manages cloud and coarse material. It does not automatically use the clear-juice clarification and filtration train.
View route →CLEARCONCENTRATE
Clear apple juice concentrate
Concentration adds evaporation, condensate, energy and possibly aroma-handling interfaces. It does not remove the need to define clarification performance.
View route →CLOUDYCONCENTRATE
Cloudy apple concentrate assessment
This is a distinct product-development and selection case. Confirm concentrate behaviour and the required product after any later reconstitution, rather than assuming clear-concentrate settings transfer.
View route →MATERIAL STREAMS
Three outputs that
must stay separate.
A process diagram that only draws juice hides the streams that constrain the layout and the cleaning plan.
Pomace
Pomace leaves the press as a separate stream. Collection height, container movement and removal frequency belong in the pressing scope.
Cleaning & waste
Cleaning is an independent operating state. Water, chemicals, return circuits and drainage need their own drawing and schedule.
NEXT STEP
Turn the flow into
a comparable brief.
Use the line selector to choose clarity and concentration, then use the mass balance to state the quantity basis. The equipment pages give the machine-level selection factors.
